Accessory, Ratchet Clamps, black, 100pc. (RCTT)
Art.-Nr. 151-01529 | RCTT-PA66HIRHSUV-BK Details

  • For pre-determined clamp pressure, a tension tab is available
  • Tension tab for use with our EVO-Series hand tools
  • Built-in channel on Ratchet P-Clamp makes using Tension Tabs quick and easy

Request your individual offer now

Application The Tension Tab enables installers to apply a specific clamp tension when used with manual processing Tool of the EVO Series hand tools.
Colour Black (BK)
Fixation Method Others
Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
PART DESCRIPTION RCTT-PA66HIRHSUV-BK
Pack Cont. 100pc.
Package Content packed in bag
Product Family Tension tab
Product Group Ratchet P-Clamp accessories
Short Description Tension tab without serration, high impact modified, heat and UV stabilised, black
Type RCTT
Variant Not Serrated
Weight/Unit 0.000449kg
CE Certification No
CSA Certified No
ELV compliant (Article 4 - 2) YES
Flammability UL 94 HB
Hazardous Goods No
Operating Temperature -40 °C to +105 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US) No
UV-Stabilised Yes
Country of Origin US
Customs Number 39269097
GTIN-13 / EAN 4031026544991
Packaging 1 - Height (m) 0.02m
Packaging 1 - Length (m) 0.295m
Packaging 1 - Qty 100
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.00107
Packaging 1 - Weight (kg) 0.0529kg
Packaging 1 - Width (m) 0.182m
Packaging 3 - Height (m) 0.1698625m
Packaging 3 - Length (m) 0.20955m
Packaging 3 - Qty 300
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0057
Packaging 3 - Weight (kg) 0.2687kg
Packaging 3 - Width (m) 0.15875m
Packaging 4 - Height (m) 1.334m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 58800
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.281
Packaging 4 - Weight (kg) 73.665kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC002935
ETIM 8.0 Key EC002935
ETIM 9.0 Key EC002935
UNSPSC Key 39121702
