Ratchet O-Clamp
Art.-Nr. 151-04443 | SGROC15.5-20FT6.5-PA66HIRHSUV/TPE-BK |  Details

    Package size
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Black (BK)
    Fixation Method Fir Tree
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV), Thermoplastic Elastomer (TPE)
    PART DESCRIPTION SGROC15.5-20FT6.5-PA66HIRHSUV/TPE-BK
    Pack Cont. 10pcs.
    Package Content packed in bag
    Product Group Ratchet O-Clamp
    Type SGROC15.5-20FT6.5
    Bundle Diameter max (metric) 20.0mm
    Bundle ∅ 15.5-20.0mm
    Bundle ∅ min. 15.5mm
    Fixing Hole Shape Circular
    Height (H) 46.0mm
    Length (L) 37.0mm
    Min.Tensile Strength 445N
    Panel Thickness max. 0.6 - 6.0mm
    Width (W) 20.5mm
    for Hole ∅ (FH) 6.1 - 7.0 mm
    for Panel Thickness min - max 0.6 - 6 mm
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Halogen-free Yes
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Reusable (Yes/No) Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised Yes
    Country of Origin MX
    GTIN-13 / EAN 4031026759739
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 39121702
