Fibre Connectors
Art.-Nr. 855-14215 | PFCSC |  Details

SC Multimode Duplex Connectors

    • Features keyed connector to ensure secure mating into the adaptor
    • Suitable for 2-3mm cables
    • Connectors supplied in separate bags
    • 3.0mm boot
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Beige (BGE)
    Connector Type SC
    Description The SC Connector is a proven design which is widely used in modern optical fibre systems and is keyed to ensure correct orientation on insertion.
    PART DESCRIPTION PFCSC
    Pack Cont. 1pc.
    Package Content packed in bag
    Performance Category Multimode
    Port count 2
    Product Family Multimode SC Duplex Connector
    Product Group Fibre Connectors
    Technical Description The Multimode SC Duplex Connectors are supplied in individual bags including the connector, dust cover and a 3.0mm boot. All fibre adaptors and connectors comply with the IEC874-14 standard ensuring inter-operability.
    Type PFCSC
    Height (H) 9.3mm
    Width (W) 28mm
    Optical Performance Multimode
    Country of Origin JP
    Dimensions W x H x D 28 mm x 9.3 mm x
    GTIN-13 / EAN 4031026328805
    Packaging 3 - Height (m) 0.142875m
    Packaging 3 - Length (m) 0.5159375m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0229m³
    Packaging 3 - Width (m) 0.31115m
    ETIM 7.0 Key EC000034
    ETIM 8.0 Key EC000034
    ETIM 9.0 Key EC000034
    UNSPSC Key 43223310
