EC4-PA66HIRHS-BK
Art.-Nr. 150-76000 | EC4-PA66HIRHS-BK |  Details

T50ROSEC10 fitted onto a plastic panel to hold a Ø 6 mm harness.

    Package size
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Anti rotation (Yes / No) YES
    Colour Black (BK)
    Description NOT to be included in catalogue or sold as seperate parts
    Internet Customer Notice Scroll down for alternative automation-ready products.
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    No. of sides for tie attachment 4
    PART DESCRIPTION EC4-PA66HIRHS-BK
    Pack Cont. 10000pcs.
    Package Content packed in box
    Type EC4
    Weight/Unit 0.00151kg
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    Specifications ANSI/UL 1565, ANSI/UL 746B, csa-C22.2 no. 62275
    UL Type 1
    Country of Origin DE
    Customs Number 39269097
    GTIN-13 / EAN 4031026217246
    Packaging 1 - Height (m) 0.8m
    Packaging 1 - Length (m) 0.6m
    Packaging 1 - Qty 10000
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.192m³
    Packaging 1 - Weight (kg) 15.165411kg
    Packaging 1 - Width (m) 0.4m
    Packaging 3 - Height (m) 0.184m
    Packaging 3 - Length (m) 0.58m
    Packaging 3 - Qty 10000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0406m³
    Packaging 3 - Weight (kg) 15.765411kg
    Packaging 3 - Width (m) 0.38m
    Packaging 4 - Height (m) 1.248m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 240000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.198m³
    Packaging 4 - Weight (kg) 399.36kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121717
