TAN33-19-PO-X-BK
Art.-Nr. 318-60105 | TAN33-19-PO-X-BK |  Details

TA30 / TA40.

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Behaviour At Low Temperature not cracking
    Colour Black (BK)
    Material Polyolefin, cross-linked (PO-X)
    PART DESCRIPTION TAN33-19-PO-X-BK
    Pack Cont. 60m
    Package Content packed in box
    Printable No
    Shrink Ratio 3:1
    Type TAN33-19
    Variant Thin-Wall
    With inner glue (Yes/No) Yes
    Length (L) 1m
    Longitudinal Change After Shrinkage +/-10% max
    Recov. ∅ d max. 6.4mm
    Supplied ∅ D min. 19.0mm
    Tolerance +/- ±0.8%
    Tube Shape Flat
    Wall (WT) 2.00mm
    Wire Size Range (mm²) 8.6-16.4mm²
    CSA Certified Yes
    Dielectric Strength 20kV/mm
    Elongation at break 3
    Halogen-free No
    Min. Shrink Temperature - °C +110 °C
    Operating Temperature -55 °C to +125 °C
    ROHS compliant Yes
    Softening Point Adhesive +80 °C
    Specifications
    Specifications CSA
    Tensile Strength 12MPa
    UL OCD link Link Link
    UL Recognized (US and Canada) Yes
    UL-File Number E143529
    Volume Resistance 10¹⁴ Ω cm
    Country of Origin CN
    GTIN-13 / EAN 4031026321011
    ETIM 7.0 Key EC000217
    ETIM 8.0 Key EC000217
    ETIM 9.0 Key EC000217
    UNSPSC Key 39121723
