Insulation Tubing
Art.-Nr. 172-00165 | PPVCB300X90WE-PVC-WH |  Details

    • Commercial grade PVC sleeving
    • good for insulation and identification applications
    Add to watchlist

    Request your individual offer now

     Request quote
    Application A commercial grade of PVC sleeving with a high temperature rating.
    Colour White (WH)
    Description PVC Sleeving
    Material Polyvinylchloride (PVC)
    PART DESCRIPTION PPVCB300X90WE-PVC-WH
    Pack Cont. 399pcs.
    Package Content packed in box
    Product Family PVC Sleeving
    Product Group Insulation Tubing
    Type PPVCB300X90WE
    Inside Ø (ID) 30mm
    Supplied ∅ D min. 30.0mm
    Wall (WT) 0.85mm
    Weight/Unit 0.75kg
    Dielectric Strength 40kV/mm
    Dielectric Strength test method IEC 60684 P2
    Flammability UL 94 HB
    Halogen-free No
    Operating Temperature -30 °C to +105 °C, intermittent +135 °C
    ROHS compliant Yes
    Shelf Life 5 years
    Specifications
    Specifications BS-2848 Type 3
    Tensile Strength 19MPa
    Test Method Tensile Strength IEC 60684 P2
    Country of Origin GB
    Customs Number 3917320090
    GTIN-13 / EAN 5022660176807
    Packaging 1 - Height (m) 0.28m
    Packaging 1 - Length (m) 0.065m
    Packaging 1 - Volume (m³) 0.00546m³
    Packaging 1 - Weight (kg) 0.75kg
    Packaging 1 - Width (m) 0.30m
    Storage Temperature 0 °C to +40 °C
    ETIM 7.0 Key EC002254
    ETIM 8.0 Key EC002254
    ETIM 9.0 Key EC002254
    UNSPSC Key 39121721
    Heat shrink tubing Heat shrink tubing

    Heat shrink tubing

    You are looking for the heat shrink tubing meeting your application requirements best? The key factors to which we owe our success are the unique and quite specific properties of our heat shrink tubing.
