LTS038-FMC-050-NPB/PA6-ML
Art.-Nr. 166-90398 | LTS038-FMC-050-NPB/PA6-ML |  Details

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Metal (ML)
    Material Nickel Plated Brass (NPB), Polyamide 6 (PA6)
    PART DESCRIPTION LTS038-FMC-050-NPB/PA6-ML
    Pack Cont. 10pcs.
    Package Content packed in pack
    Thread type NPT
    Type LTS038-FMC-050
    Variant Straight
    Bore Diameter (Imperial) 0.42"
    Bore Diameter (metric) 10.7
    Height (H) 26.0mm
    Length (L) 24.0mm
    Nominal ∅ 0.38"
    Nominal ∅ 16.0mm
    Thread Length (TL) 13mm
    Thread Length (TL) (Imperial) 0.51"
    Thread Size (Imperial) 1/2 "
    Wrenching Flat Size (Imperial) 0.83"
    Wrenching Flat Size (Metric) 21mm
    CSA Certified No
    Halogen-free Yes
    IP-Rating IP68
    Operating Temperature -50 °C to +135 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) Yes
    UL Listed (US and Canada) Yes
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UL-File Number E247502
    UV-Stabilised No
    Country of Origin GB
    GTIN-13 / EAN 4031026520711
    UNSPSC Key 39131707
    Metal conduits Metal conduits

    Metal conduits

    Metal conduits from HellermannTyton: Standard metal conduits, coated metal conduits, liquid tight metal conduits and matching metal conduit fittings. Discover now!
