Divisible seals EZA-t mini.
Art.-Nr. 874-50034 | EZA-t_12/4.0-4.5_mini-BK/VT Details

  • gas- and water-tight up to 0.5 bar
  • reusable
  • tool-less installation
  • optimally suited for retrofitting
  • perfect supplement for tight space conditions in cable distributors
  • not suitable for direct burial
  • suitable for speedpipe ground 12x2.0
Show more

Request your individual offer now

Application The tensile, gas and watertight sealing elements EZA-t mini are suitable for sealing speedpipe ground with cable / fiber optic cable. Due to thier compact design, they have been specially developed for limited space and hard-to-reach places. Due to the slotted design, subsequent installation is also possible. The different coloured rubber sealings make ist easy to differentiate between the individual sealing areas.
Cable ∅ max 4.5mm
Cable ∅ min 4mm
Colour Violet (VT), Black (BK)
Local order number 4282
PART DESCRIPTION EZA-t_12/4.0-4.5_mini-BK/VT
Pack Cont. 50
Package Content packed in carton
Product Family EZA-t 12/4,0-4,5 mini
Product Group Divisible seals EZA-t mini.
Type EZA-t_12/4.0-4.5_mini
Diameter (D) 12mm
Country of Origin DE
GTIN-13 / EAN 4031051042820
Packaging 1 - Type carton
Packaging 3 - Type pallet
ETIM 7.0 Key EC000000
ETIM 8.0 Key EC000000
ETIM 9.0 Key EC000000
