speedpipe indoor.
Art.-Nr. 871-00107 | speedpipe-indoor_7x1.5-PE-HD Details

  • fire tests according to the legal safety objectives
  • installation and laying instructions available
  • can be used in combination with firewalls
  • inner side furnished with optimised slide ribs, therefore optimally applicable for blowing and pulling in micro cables
  • not flame spreading and halogen free according to EN 60684-2 and low smoke density according to EN 61034-2
  • speedpipe indoor are delivered on a wooden or plastic spool (box) which is optimised for shipment and installation
Show more
Package size

Request your individual offer now

Application The speedpipe indoor were developed by gabocom especially for the application inside buildings. They are not flame spreading and were tested in accordance with the standards DIN EN 13501-1, DIN EN 60332-1-2 and regarding the absence of halogens according to DIN EN 60684-2. Furthermore, the speedpipe indoor were tested in accordance with DIN EN 61386-22 (VDE 0605) for a clear definition of their laying.
PART DESCRIPTION speedpipe-indoor_7x1.5-PE-HD
Package Content packed in drum
Product Family Fire protection and safe networks inside the building.
Product Group speedpipe indoor.
Type speedpipe-indoor_7x1.5
Diameter (D) 7mm
Pressure Nominal (PN) PN 16
Wall (WT) 1.5mm
Weight/Unit 0.028kg
CE Certification Yes
Packaging 1 - Type drum
Packaging 1 - Weight (kg) 14kg
Packaging 2 - Type pallet
ETIM 7.0 Key EC000000
ETIM 8.0 Key EC000000
ETIM 9.0 Key EC000000
