HGL200-S-2000-PA66-BK
Art.-Nr. 166-90775 | HGL200-S-2000-PA66-BK |  Details

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Black (BK)
    Material Polyamide 6.6 (PA66)
    PART DESCRIPTION HGL200-S-2000-PA66-BK
    Pack Cont. 1pc.
    Package Content packed in pack
    Thread type NPT
    Type HGL200-S-2000
    Bore Diameter (Imperial) 2.09"
    Bore Diameter (metric) 53
    Length (L) 74.0mm
    Nominal ∅ 2.63"
    Nominal ∅ 67mm
    Outside Ø (OD) 87.0mm
    Outside ∅ (OD) 3.43"
    Thread Length (TL) 20mm
    Thread Length (TL) (Imperial) 0.79"
    CE Certification No
    CSA Certified No
    Flammability UL 94 V2
    Halogen-free Yes
    IP-Rating IP68
    Operating Temperature -50 °C to +135 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) Yes
    UL Listed (US and Canada) Yes
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UL-File Number E247502
    UV-Stabilised No
    Country of Origin GB
    GTIN-13 / EAN 4031026572796
    ETIM 7.0 Key EC001176
    ETIM 8.0 Key EC001176
    ETIM 9.0 Key EC001176
    UNSPSC Key 39131601
