Cable Organizer
Art.-Nr. 161-08079 | SPIRAL 1/2"-PE-GY |  Details

SBPEFR spiral binding is available in several diameters and in the colours black and white.

    • Organizes and protects cables
    • Flexible
    • Ensures perfect accommodation next to the whip
    • Allows derivations
    • Also available in 2-meter packages for small-scale use
    Show more
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application Versatile system of organization and protection of cables that guarantees perfect accommodation next to the whip, besides allowing derivation at any point of the installation.
    Colour Grey (GY)
    Material Polyethylene (PE)
    PART DESCRIPTION SPIRAL 1/2"-PE-GY
    Pack Cont. 2m
    Package Content packed in bag
    Product Family Spiral Tube
    Product Group Cable Organizer
    Type SPIRAL 1/2"
    Variant Spiral Binding
    Bundle Diameter max (metric) 38.0mm
    Bundle ∅ 9.5-38.0mm
    Bundle ∅ min. 9.5mm
    Nominal ∅ 0.5"
    Nominal ∅ 12.0mm
    Pitch (P) 15.6mm
    Wall (WT) 1.1mm
    Flammability UL 94 HB
    Halogen-free Yes
    Operating Temperature -40 °C to +80 °C
    ROHS compliant Yes
    Specifications
    Country of Origin BR
    GTIN-13 / EAN 7890176092540
    ETIM 7.0 Key EC002604
    ETIM 8.0 Key EC002604
    ETIM 9.0 Key EC002604
    Show all
    Cable wraps, spiral wraps Cable wraps, spiral wraps

    Cable wraps, spiral wraps

    From standard spiral hoses for office use to flame retardant spiral cable wraps to heat and chemical resistant cable wraps for industry: Discover our portfolio here.
