Cable marker, 38.1x6.35mm, orange, pack=25pcs.
Art.-Nr. 598-00004 | TYHC34-66-TYHC-OG |  Details

Label material is a conformable cloth that ensures markers stay on wires and cables for the life of the application.

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application 34 - 66 Sequence Handi-Card
    Colour Orange (OG)
    Material Vinyl Cloth (TYHC)
    PART DESCRIPTION TYHC34-66-TYHC-OG
    Pack Cont. 25pcs.
    Package Content packed in pack
    Type TYHC34-66
    Bundle Diameter max (metric) 7.50mm
    Bundle ∅ 3.40-7.50mm
    Bundle ∅ min. 3.40mm
    Height (H) 38.10mm
    Length (L) 38.1mm
    Outside ∅ max (OD max.) 7.50mm
    Outside ∅ max. 0.29"
    Outside ∅ min. 0.13"
    Outside ∅ min. (OD min.) 3.40mm
    Width (W) 6.35mm
    Adhesive Rubber
    Adhesive Operating Temperature -40 °C to +120 °C
    CE Certification No
    CSA Certified No
    Curing Temperature from +10 °C
    Halogen-free No
    Operating Temperature -40 °C to +120 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    Country of Origin US
    GTIN-13 / EAN 4031026724676
    Labels per Column 1
    Labels per Row 33
    Labels per Sheet 33
    ETIM 7.0 Key EC001530
    ETIM 8.0 Key EC001530
    ETIM 9.0 Key EC001530
    UNSPSC Key 39131507
