Fixing tie for hole (round), outside serrated, ∅95.0mm, black, 50pcs.
Art.-Nr. 156-00365 | T120ROSFT11-PA66HS/PA66HSUV-BK |  Details

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application Primarily designed for fixing cable harnesses in the automotive industry their simplicity, and ease of use, has seen these parts used in everything from aircraft, to switch-gear, to washing machines.
    Application Tool ProCut 9 no battery, EVOcut, MK9P, MK9P w/ Upper air, MK10-SB, MK21, EVO9, EVO9SP, EVO9HT, EVO9i, EVO9iSP, EVO9iHT
    Colour Black (BK)
    Description These two-piece fixings are supplied ready assembled and offer a simple and versatile method of bundling and fixing cables. The fir-tree base will easily push into pre-punched holes in panels or threaded, blind, holes and offers a very secure fixing. The two-piece design enables the head of the tie to be orientated to the required position to ease assembly, whilst the 'disc' on the top of the fir tree covers the hole and minimises the ingress of water and dirt.
    Fixation Method Fir Tree
    Identification Plate Position none
    Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, heat and UV-stabilised (PA66HSUV)
    PART DESCRIPTION T120ROSFT11-PA66HS/PA66HSUV-BK
    Pack Cont. 50pcs.
    Package Content packed in bag
    Product Family Fir tree parts FT11
    Product Group 2-piece fixing ties with fir tree, with disc, for round holes
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T120ROSFT11
    Variant Outside Serrated
    Bundle Diameter max (metric) 95.0mm
    Bundle ∅ 95.0mm
    Disc ∅ 16mm
    Hole Depth 8.2mm
    Length (L) 385mm
    Length (L2) 16.5mm
    Min.Tensile Strength 535N
    Thickness (T) 1.8mm
    Width (W) 7.6mm
    Width (W3) 0mm
    for Hole ∅ (FH) 6.5 - 7.0 mm
    for Panel Thickness min - max 0.8 - 4.5 mm
    Flammability UL 94 V2
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    Country of Origin GB
    GTIN-13 / EAN 4944387951349
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121717
