Fixing tie for hole (round), ∅2.0-50.0mm, black, 3000Carton
Art.-Nr. 157-00413 | T50ROSFT1012.5SO-PA66HIRHSUV-BK |  Details

T50ROSFT6S25SO and T50ROSFT612.5SO.

    • Bundling and fixing solution
    • Ideal combination of materials and design
    • Different positions of the fixing anchor are available to fit installation space
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Cable Tie Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    Cable ∅ max 50mm
    Cable ∅ min 2.0mm
    Colour Black (BK)
    Fixation Method Fir tree for round holes
    Identification Plate Position none
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    PART DESCRIPTION T50ROSFT1012.5SO-PA66HIRHSUV-BK
    Pack Cont. 3000Carton
    Package Content packed in carton
    Product Family With offset 12.5 and 25.0 mm
    Product Group 1-piece fixing ties with fir tree, with disc, with stand-off, for round holes
    Releasable Closure (Yes/No) No
    Short Description 1-Piece Fixing Ties with Fir Tree and Disc, with Stand-off, for Round Holes
    Type T50ROSFT1012.5SO
    Attach to Ø 10
    Bundle Diameter max (metric) 50.0mm
    Bundle ∅ 2.0-50.0mm
    Bundle ∅ min. 2.0mm
    Depth (D) 17.0mm
    Disc ∅ 17.0mm
    Height (H) 21.0mm
    Hole Depth 0.6mm
    Hole Depth 6.0mm
    Length (L) 216.4mm
    Length (L2) 12.5mm
    Min.Tensile Strength 220N
    Offset Length 12.5mm
    Panel Thickness max. 0.6 - 6.0mm
    Weight/Unit 0.00242kg
    Width (W) 5.08mm
    for Hole ∅ (FH) 9.6 - 10.4 mm
    for Panel Thickness min - max 0 - 0.2 "
    for Panel Thickness min - max 0.6 - 6 mm
    CE Certification No
    CSA Certified No
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 HB
    Halogen-free No
    Hazardous Goods No
    Operating Temperature -40 °C to +110 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised Yes
    Country of Origin MX
    Customs Number 39269097
    GTIN-13 / EAN 4031026702292
    Packaging 1 - Qty 3000
    Packaging 1 - Type bag
    Packaging 1 - Weight (kg) 7.260001kg
    Packaging 3 - Height (m) 0.3730625m
    Packaging 3 - Length (m) 0.587375m
    Packaging 3 - Qty 3000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.063m³
    Packaging 3 - Weight (kg) 8.080001kg
    Packaging 3 - Width (m) 0.2873375m
    Packaging 4 - Height (m) 1.263m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 36000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.212m³
    Packaging 4 - Weight (kg) 117.96kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121717
