Cable tie endless, 610.0x12.7mm, black, 25pcs.
Art.-Nr. 111-32109 | TELS-24STRAP-POM-BK |  Details

The EL-TY strap can be cut to suit any bundle.

    • Made of very strong Polyacetal (POM)
    • System consists of endless strap, spacers and heads
    • Head includes stainless steel pawls for a proper fixation
    • Very secure fixing and good resistance to ageing and UV light
    • Suits any bundle diameter and reduces inventory
    Show more
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application These robust cable ties are particularly suitable for use with larger diameter cables, pipes and hoses. Designed originally for securing overhead catenary and cables, they are now used in many industries from the building sector, through to the chemical industry, to the installation of signs for traffic management. Separate spacers allow for a defined distance when bundling in parallel.
    Cable Tie Polyacetal (POM)
    Colour Black (BK)
    Fixation Method 2 piece
    Identification Plate Position none
    Material Polyacetal (POM)
    Material Head Polyacetal (POM)
    Material Spacer Polypropylene, UV-resistant (PPW)
    PART DESCRIPTION TELS-24STRAP-POM-BK
    Pack Cont. 25pcs.
    Package Content packed in reel
    Product Family EL-TY-Series
    Product Group Endless cable ties with separate head and spacer
    Releasable Closure (Yes/No) No
    Tie Closure steel pawl
    Type TELS-24STRAP
    Variant Endless
    Length (L) 610.0mm
    Min.Tensile Strength 1115N
    Width (W) 12.7mm
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Operating Temperature -40 °C to +90 °C
    Operating Temperature Head (Metric) -40 °C to +85 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    Country of Origin US
    GTIN-13 / EAN 4031026421490
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
