Connector clip for hole (round), black, 1000pcs.
Art.-Nr. 151-01539 | CCIVSFT6513T4-PA66-BK |  Details

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Black (BK)
    Material Polyamide 6.6 (PA66)
    PART DESCRIPTION CCIVSFT6513T4-PA66-BK
    Pack Cont. 1000pcs.
    Product Family With Arrowhead
    Product Group Connector Clips for Oval Holes
    Type CCIVSFT6513T4
    Height (H) 15.6mm
    Length (L) 19.6mm
    Panel Thickness max. 0.6 - 4.0mm
    Weight/Unit 0.001369kg
    Width (W) 23.6mm
    for Hole ∅ (FH) 6.5 x 13.0 mm
    for Panel Thickness min - max 0.6 - 4 mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    ROHS compliant Yes
    Specifications
    Country of Origin KR
    Customs Number 39269097
    GTIN-13 / EAN 4031026545691
    Packaging 1 - Height (m) 0.05m
    Packaging 1 - Length (m) 0.43m
    Packaging 1 - Qty 1000
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00645m³
    Packaging 1 - Weight (kg) 1.369001kg
    Packaging 1 - Width (m) 0.3m
    Packaging 3 - Height (m) 0.215m
    Packaging 3 - Length (m) 0.575m
    Packaging 3 - Qty 8000
    Packaging 3 - Type carton
    Packaging 3 - Volume (m³) 0.0476m³
    Packaging 3 - Weight (kg) 11.452kg
    Packaging 3 - Width (m) 0.385m
    Packaging 4 - Height (m) 1.219m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 160000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.17m³
    Packaging 4 - Weight (kg) 250.04kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 39121702
