Identification ties and plates for marking cable bundles
Art.-Nr. 151-00877 | AT1-PA66-BK |  Details

A clearly better way of identifying cables and pipes.

    • Blank nylon arrowhead shape plate fixed with a cable tie
    • Identify with a T82 pen or Ovalgrip markers
    • AT1 for 7 size 50 Ovalgrip markers
    • AT2 for 8 size 85 Ovalgrip markers
    • AT3 for 14 size 85 Ovalgrip markers
    • Custom printed plaques are available on request
    Show more
    Package size
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application The plates are suitable for applying to larger pipes and cables before or after termination has taken place. They can be marked with Ovalgrip markers or manually using the T82 series of indelible markers pens.
    Colour Black (BK)
    Fixation Method Others
    Identification Plate Position attached to bundle
    Marker tiles per carrier 9
    Material Polyamide 6.6 (PA66)
    PART DESCRIPTION AT1-PA66-BK
    Pack Cont. 1000pcs.
    Package Content packed in bag
    Product Family Arrowtag
    Product Group Identification ties and plates for marking cable bundles
    Recommended Labels HO50
    Recommended Ovalgrip Size 50
    Type AT1
    Variant Other
    With label space Yes
    Length (L) 63mm
    Strap Width max. (G) 7.40mm
    Width (W) 4.60mm
    Flammability UL 94 V2
    Halogen-free Yes
    Operating Temperature -40 °C to +85 °C
    ROHS compliant Yes
    Specifications
    Country of Origin BR
    GTIN-13 / EAN 7890176003249
    ETIM 7.0 Key EC001530
    ETIM 8.0 Key EC001530
    ETIM 9.0 Key EC001530
