Cable tie outside serrated, 370x7.6mm, ∅14.0-106mm, black, 100pcs.
Art.-Nr. 132-00002 | LHT370-PA66-BK |  Details

BHT375 - used for mounting cables via a single hole.

    • Both sides serrated cable tie
    • BHT-Series with round head for larger bearing area
    • BHT375 for centred position
    • CT- and LHT-Series with small squared head for restricted space areas
    • Tensioning with application tool
    Show more
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application Using a single hole these 'chassis ties' are widely used in the automotive, truck and heavy equipment markets. Ideal for applications which have access to both sides of the hole - example truck frame rails.
    Cable Tie Polyamide 6.6 (PA66)
    Colour Black (BK)
    Identification Plate Position none
    Key product features for direct fixation
    Material Polyamide 6.6 (PA66)
    Material Head Polyamide 6.6 (PA66)
    PART DESCRIPTION LHT370-PA66-BK
    Pack Cont. 100pcs.
    Package Content packed in bag
    Product Family Chassis ties
    Product Group Cable ties for single hole application
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type LHT370
    Variant Outside Serrated
    Bundle Diameter max (metric) 106mm
    Bundle ∅ 14.0-106mm
    Bundle ∅ min. 14.0mm
    Height (H) 1.8mm
    Length (L) 370mm
    Min.Tensile Strength 535N
    Weight/Unit 0.0038kg
    Width (W) 7.6mm
    for Hole ∅ (FH) 8.5 mm
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 V2
    Hazardous Goods No
    Operating Temperature -40 °C to +85 °C
    ROHS compliant Yes
    Specifications
    Country of Origin PL
    Customs Number 39269097
    GTIN-13 / EAN 5022660309076
    Packaging 1 - Height (m) 0.13m
    Packaging 1 - Length (m) 0.4m
    Packaging 1 - Qty 100
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.01664m³
    Packaging 1 - Weight (kg) 0.3955kg
    Packaging 1 - Width (m) 0.32m
    Packaging 3 - Height (m) 0.184m
    Packaging 3 - Length (m) 0.58m
    Packaging 3 - Qty 2000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0406m³
    Packaging 3 - Weight (kg) 8.51kg
    Packaging 3 - Width (m) 0.38m
    Packaging 4 - Height (m) 1.248m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 48000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.198m³
    Packaging 4 - Weight (kg) 225.48kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
