Fixing tie for hole (oval), outside serrated, ∅1.8-50.0mm, black, 2500pcs.
Art.-Nr. 157-00458 | T50ROSFTOVAL15R-PA66HIRHSUV-BK Details

  • Bundling and fixing solution
  • Ideal combination of materials and design
  • Different positions of the fixing anchor are available to fit installation space
  • 1-Piece Fixing Tie with defined offset 12.5 and 25.0 mm

Request your individual offer now

Colour Black (BK)
Fixation Method Fir Tree for oval holes
Identification Plate Position none
Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
PART DESCRIPTION T50ROSFTOVAL15R-PA66HIRHSUV-BK
Pack Cont. 2500pcs.
Package Content packed in bag
Product Family with offset 12.5 and 25.0 mm
Product Group 1-piece fixing ties with fir tree, with disc, with stand-off, for oval holes
Releasable Closure (Yes/No) No
Type T50ROSFTOVAL15R
Variant Outside Serrated
Bundle Diameter max (metric) 50.0mm
Bundle ∅ 1.8-50.0mm
Bundle ∅ min. 1.8mm
Disc ∅ 17.63 x 23.63mm
Fixing Hole Shape Oval
Height (H) 19.85mm
Length (L) 227.0mm
Length (L2) 15.0mm
Min.Tensile Strength 220N
Offset Length 15.0mm
Panel Thickness max. 0.6 - 6.75mm
Weight/Unit 0.0031kg
Width (W) 23.6mm
for Hole ∅ (FH) 6.2 x 12.2 mm, 6.5 x 12.5 mm, 6.5 x 13.0 mm, 7.0 x 12.0 mm
for Panel Thickness min - max 0.6 - 6.8 mm
for Panel Thickness min - max 0 - 0.3 "
CE Certification No
ELV compliant (Article 4 - 2) YES
Flammability UL 94 HB
Hazardous Goods No
Operating Temperature -40 °C to +135 °C, (+140 °C, 500 h)
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US) No
UV-Stabilised Yes
Country of Origin US
Customs Number 39269097
GTIN-13 / EAN 4031026702421
Packaging 1 - Height (m) 0.3556m
Packaging 1 - Length (m) 0.5842m
Packaging 1 - Qty 2500
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.05804
Packaging 1 - Weight (kg) 7.750001kg
Packaging 1 - Width (m) 0.2794m
Packaging 3 - Height (m) 0.37465m
Packaging 3 - Length (m) 0.59055m
Packaging 3 - Qty 2500
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0646
Packaging 3 - Weight (kg) 8.570001kg
Packaging 3 - Width (m) 0.2921m
Packaging 4 - Height (m) 1.269m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 30000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.218
Packaging 4 - Weight (kg) 123.84kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121717
