23/12/2024

Fixing tie for hole (oval), outside serrated, ∅2.0-50.0mm, grey, 2500pcs.
Art.-Nr. 157-00518 | T50ROSFTOVAL25A-PA66HIRHS-GY |  Details

The fir tree mount cable tie is an all-in-one bundling and fastening solution that reduces costs and assembly time.

    • Bundling and fixing solution
    • Ideal combination of materials and design
    • Different positions of the fixing anchor are available to fit installation space
    • 1-Piece Fixing Tie with defined offset 12.5 and 25.0 mm
    Package size
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Grey (GY)
    Fixation Method Fir Tree for oval holes
    Identification Plate Position none
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION T50ROSFTOVAL25A-PA66HIRHS-GY
    Pack Cont. 2500pcs.
    Package Content packed in carton
    Product Family with offset 12.5 and 25.0 mm
    Product Group 1-piece fixing ties with fir tree, with disc, with stand-off, for oval holes
    Releasable Closure (Yes/No) No
    Type T50ROSFTOVAL25A
    Variant Outside Serrated
    Bundle Diameter max (metric) 50.0mm
    Bundle ∅ 2.0-50.0mm
    Bundle ∅ min. 2.0mm
    Disc ∅ 17.63 x 23.63mm
    Fixing Hole Shape Oval
    Height (H) 13.15mm
    Length (L) 229.3mm
    Length (L2) 25.0mm
    Min.Tensile Strength 222.4N
    Offset Length 25.0mm
    Panel Thickness max. 0.6 - 6.75mm
    Thickness (T) 1.35mm
    Width (W) 4.7mm
    for Hole ∅ (FH) 6.2 x 12.2 mm, 6.5 x 12.5 mm, 6.5 x 13.0 mm, 7.0 x 12.0 mm
    for Panel Thickness min - max 0.6 - 6.8 mm
    for Panel Thickness min - max 0 - 0.3 "
    CE Certification No
    CSA Certified No
    Operating Temperature -40 °C to +110 °C
    ROHS compliant Yes
    Specifications
    UV-Stabilised No
    Country of Origin MX
    GTIN-13 / EAN 4031026657721
    Packaging 3 - Qty 2500
    Packaging 4 - Qty 60000
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121717
