Fixing tie for hole (round), inside serrated, ∅9.5-105.0mm, black, 100pcs.
Art.-Nr. 156-00074
| WSRFT9B-PA66HIRHSUV-BK
|
Details
- Pre-assembled 2-piece fixing tie with fir tree foot part
- Cable tie head can be moved after bundling
- Easy to assemble without the need for a tool
- Disc adjusts tie for pressure from various directions and minimises access of dust and dirt
- Fir tree foot part can be used for a variety of panel thicknesses
- Suitable for use within threaded holes
Request your individual offer now
Request quote
More products in this product group:
Application | Primarily designed for fixing cable harnesses in the automotive industry their simplicity, and ease of use, has seen these parts used in everything from aircraft, to switch-gear, to washing machines. |
Colour | Black (BK) |
Fixation Method | Fir tree for round holes |
Identification Plate Position | none |
Material | Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV) |
PART DESCRIPTION | WSRFT9B-PA66HIRHSUV-BK |
Pack Cont. | 100pcs. |
Package Content packed in | bag |
Product Family | Fir tree parts FT9 |
Product Group | 2-piece fixing ties with fir tree, with disc, for round holes |
Tie Closure | plastic pawl |
Type | WSRFT9B |
Variant | Inside Serrated |
Bundle Diameter max (metric) | 105.0mm |
Bundle ∅ | 9.5-105.0mm |
Bundle ∅ min. | 9.5mm |
Disc ∅ | 21.6mm |
Height (H) | 28.40mm |
Height (H2) | 18.40mm |
Length (L) | 383.5mm |
Min.Tensile Strength | 535N |
Panel Thickness max. | 1.0 - 15.8mm |
Weight/Unit | 0.009184kg |
Width (W) | 12.7mm |
Width (W2) | 13.0mm |
for Hole ∅ (FH) | 8.7 - 9.2 mm |
for Panel Thickness min - max | 1 - 15.8 mm |
for Panel Thickness min - max | 0 - 0.6 " |
CE Certification | No |
CSA Certified | No |
ELV compliant (Article 4 - 2) | YES |
Flammability | UL 94 HB |
Hazardous Goods | No |
Operating Temperature | -40 °C to +105 °C |
ROHS compliant | Yes |
Specifications | |
UL Listed (US and Canada) | No |
UL Listed (US and Canada) | No |
UL Recognized (US and Canada) | No |
UL Recognized (US and Canada) | No |
UV-Stabilised | Yes |
|
|
Country of Origin | US |
Customs Number | 39269097 |
GTIN-13 / EAN | 4031026419442 |
Packaging 1 - Height (m) | 0.075m |
Packaging 1 - Length (m) | 0.615m |
Packaging 1 - Qty | 100 |
Packaging 1 - Type | bag |
Packaging 1 - Volume (m³) | 0.01637m³ |
Packaging 1 - Weight (kg) | 0.9594kg |
Packaging 1 - Width (m) | 0.355m |
Packaging 2 - Type | carton |
Packaging 3 - Height (m) | 0.20954999999999998m |
Packaging 3 - Length (m) | 0.6048375m |
Packaging 3 - Qty | 500 |
Packaging 3 - Type | box |
Packaging 3 - Volume (m³) | 0.0501m³ |
Packaging 3 - Weight (kg) | 5.657kg |
Packaging 3 - Width (m) | 0.39528749999999997m |
Packaging 4 - Height (m) | 1.194m |
Packaging 4 - Length (m) | 1.2m |
Packaging 4 - Qty | 7500 |
Packaging 4 - Type | pallet |
Packaging 4 - Volume (m³) | 1.146m³ |
Packaging 4 - Weight (kg) | 105.855kg |
Packaging 4 - Width (m) | 0.8m |
